316Ti Stainless Steel
316Ti is a titanium stabilized austenitic stainless steel in the 316 family. It contains 16% to 18% chromium, 10% to 14% nickel, 2% to 3% molybdenum, and titanium at ≥5×C%. Titanium stabilizes carbides and improves resistance to intergranular corrosion, especially after welding or at elevated temperature. The alloy resists sulfuric, phosphoric, and acetic acid, as well as chloride solutions. The source lists continuous service up to 800℃, good toughness and workability, a nonmagnetic austenitic structure, and suitability for chemical, food, and medical equipment.
Product details
Chemical composition
| 316Ti | C | Si | Mn | P | S | Ni | Cr | Mo | Ti |
|---|---|---|---|---|---|---|---|---|---|
| min | – | – | – | – | – | 10.0 | 16.0 | 2.0 | 5.0*C |
| max | 0.08 | 1.0 | 2.0 | 0.045 | 0.03 | 14.0 | 18.0 | 3.0 | – |
Scroll horizontally to view all values.
Grade equivalents
| English Item | UNS | W.Nr. | JIS | GB/T | Other Grades |
|---|---|---|---|---|---|
| 316Ti | S31635 | 1.4571 | SUS316Ti | 06Cr17Ni12Mo3Ti | 08X17H13M3T X6CrNiMoTi17-12-2 |
Scroll horizontally to view all values.
Physical properties
| Density g/cm³ | 7.98 |
|---|---|
| Melting range ℃ | 1300-1350 |
| Thermal conductivity (100℃) λ/(W/m•℃) | 16.2 |
| Specific heat J/kg•℃ | 500 |
| Elastic modulus GPa | 193 |
| Electrical resistivity μΩ•m | 0.74 |
| Linear expansion coefficient a/10-6℃-1 | 16 |
Scroll horizontally to view all values.
Mechanical properties
| Tensile strength Rm N/mm | ≥530 |
|---|---|
| Yield strength RP0.2 N/mm | ≥205 |
| Elongation % | ≥40 |
| Hardness HB | ≤187 |
| *After solution heat treatment | |
Scroll horizontally to view all values.
Applications
- Chemical equipment: reactors, heat exchangers, and tanks handling corrosive media such as sulfuric and phosphoric acid
- Food processing: beverage-production lines, storage vessels, and processing equipment that meet hygiene standards
- Medical equipment: corrosion-resistant, easy-to-clean surgical instruments and sterilization equipment
- Marine engineering: seawater-desalination equipment and offshore-platform piping exposed to chlorides
- Environmental equipment: wastewater piping and waste-gas treatment units exposed to acidic and alkaline conditions
- Petrochemical service: sulfur-bearing oil and gas piping and refinery equipment exposed to hydrogen sulfide and acidic media
- High-temperature equipment: heat-treatment furnace components and furnace hardware for long-term service below 800℃
Available product forms
- Round Bar
- Wire
- Forgings
- Plate
- Strip
- Seamless Pipe
- Welded Pipe
- Capillary Tube
- Flanges
- Pipe Fittings
- Non-standard Custom Parts
Values follow the Milike materials catalogue and are provided for preliminary review. Confirm the applicable purchase specification, heat treatment condition, and inspection requirements before final material selection.
- Heat and batch traceability
- PMI testing available
- Cut-to-size processing
- Material certificates on request
